NPT 1022

• TDM migration: supporting voice trunk and legacy service migration with circuit emulation services (CES) mapping a full range of legacy TDM interface speeds onto the packet switched network (PSN)
• Mission critical networks for utilities, transportation and defense: with the NPT 1022M/MR providing extended temperature
  ranges, PoE++, and built-in transport card slots (T-Slots) to natively support for legacy interfaces
• Access Aggregation and CPE for Business services: provides packet transport to meet service SLAs on a per service basis
• 5G Cell site router: with 5G specific functionality including Class C timing, Segment Routing, EVPN and a built-in GNSS receiver
• Access Aggregation for backhaul: supporting 5G xHaul, broadband backhaul, business services, and TDM migration all from a
  single converged platform
• NPT 1022MR/BHR/LR: variants remove support for IPoDWDM and MPLS-TP

The NPT 1022 is available in modular and fixed form factors.  The fixed form factor variants optimize cost/performance and a port fanout of 96Gb all in a compact 1 RU form factor. There are two fixed form factor variants:

• NPT 1022L: supports IP/MPLS and MPLS-TP
• NPT 1022LR: supports IP/MPLS, it does not support MPLS-TP or IPoDWDM

The modular form factor variants provide the flexibility to allow the operators to customize their choice of traffic card according to
specific needs. There are multiple modular form factor variants:

• NPT 1022BH: supports IP/MPLS and MPLS-TP
• NPT 1022BHR: ; provides the same capabilities as the NPT 1022Bh, but does not support MPLS-TP or IPoDWDM
• NPT 1022M; supports IP/MPLS and MPLS-TP and provides increased switching capacity and two transport card slots (T-Slots)
• NPT 1022MR; provides the same capabilities as the NPT 1022M, but does not support MPLS-TP or IPoDWDM
